HydroMax Seal

Precision Mechanical Seals for Every Application

Proven Performance, Global Support

API682 Compliance: All seals are engineered to meet stringent global standards.
Durability: Designed for extreme pressures, temperatures, and abrasive slurries.
Versatility: Wide product range for oil & gas, mining, pulp & paper, wastewater, and chemical processing.
Technical Expertise: Backed by deep engineering knowledge and application-specific guidance.
Customization: Multiple seal faces, elastomers, and configurations tailored to specific needs.
Global Support: Factory testing, aftermarket service, and technical assistance worldwide.

Product Categories

Cartridge Mechanical Seals

Our cartridge seals are engineered for reduced downtime and dependable sealing integrity. Available in both single and double designs, they are API 682-compliant and built to withstand high pressures, temperatures, and abrasive fluids.

CSW-610 – Compact double seal for pumps with space limitations in pulp & paper and wastewater.
SPS-610 – Heavy-duty double cartridge seal for slurry and solids-laden applications.
SPS-625 – External-mount slurry seal with wear-resistant materials for abrasive media.
SPW-516 – Stationary double cartridge seal with integrated flow inducer for demanding operations.
RPW-215 – Single-cartridge rotary pusher seal with flush, quench, and drain ports for reliability.

Component Mechanical Seals

HydroMax component seals provide flexibility and cost efficiency for OEMs and industrial equipment. Designed for precision and durability, they cover a wide range of applications from chemical processing to general manufacturing.

RPW-032 – Single spring seal, bi-directional with O-ring, suitable for versatile shaft sizes.
RPW-041/042 – Single coil spring seals designed for Alfa Laval pump models.
RPW-041/042 – Single coil spring seals designed for Alfa Laval pump models.
RBW-021 – Metal bellows balanced seal with graphite wedge packing for high-temperature, high-pressure applications.

Mechanical Seal Comparison

Category	Model	Type	Best For	Key Highlights	Performance Specs
Cartridge Seals	CSW-610	Compact Double	Pulp & Paper, Wastewater	Space-saving design, bi-directional pumping ring, API682 compliant	Up to 25 barg, 250°C, 4,000 rpm
	SPS-610	Double Cartridge	Slurry & Solids	Vortex breakers, heat dissipation, heavy-duty slurry service	Up to 25 barg, 250°C, 4,000 rpm
	SPS-625	External Double	Mining, Abrasive Slurry	Wear-resistant materials, external mounting option	Up to 25 barg, 250°C, 4,000 rpm
	SPW-516	Stationary Double	High-Speed Equipment	Integral flow inducer, multi-spring balance	Up to 20 barg (process), 180°C, 20 m/s
	RPW-215	Single Cartridge	General Industrial	Flush, quench & drain ports, factory assembled	Up to 20 barg, 180°C, 20 m/s
Component Seals	RPW-032	Single Spring	General Purpose	Bi-directional, O-ring with set screw drive	Up to 8 barg, 10 m/s
	RPW-041/042	Single Spring	Alfa Laval Pumps	Designed for LKH and ALC2 pump models	Up to 5 barg, 10 m/s
	EMD-30/31/32	Teflon Bellows	Chemical Processing	Multi-spring, glass-filled Teflon bellows, no elastomers	Up to 5 barg, 110°C, 20 m/s
	RBW-021	Metal Bellows	High-Temp/Pressure	Graphite wedge packing, stainless & alloy options	Up to 16 barg, 180°C+, 25 m/s

Industries

Industries Served

HydroMax Seal mechanical seals are designed to perform reliably in demanding applications across various industries. Our designs meet API682 standards, withstand extreme operating conditions, and minimize downtime in demanding environments.

Oil & Gas

API-compliant cartridge and component seals for upstream, midstream, and downstream applications.

Mining & Minerals

Heavy-duty slurry seals built for abrasive, solids-laden processes.

Pulp & Paper

Reliable sealing solutions for process pumps in fiber-rich and corrosive media.

Water & Wastewater

Corrosion-resistant seals designed for pumps in treatment and distribution systems.

Chemical Processing

Teflon and metal bellows seals for aggressive, corrosive, and high-temperature fluids.

Power Generation

High-performance seals for boiler feed, cooling water, and circulating pumps.

Technical Support & Engineering Services

Seal Selection Assistance – Expert guidance to identify the right cartridge or component seal for your specific application.
API Plan Compatibility – Support for piping plans, including Plan 32, 52, 53, and 62, to ensure compliance and reliability.
Factory Testing & Validation – Every seal is assembled, pressure-tested, and verified for performance before delivery.
Aftermarket Service & Refurbishment – Comprehensive repair and refurbishment programs to extend seal life and minimize downtime.

Talk to Our Seal Specialists

From selection to support, our team is ready to solve your sealing challenges.

FAQs

Frequently Asked Questions

How do HydroMax seals support compliance with API682 and other industry standards?

Our cartridge seals are engineered in full compliance with API682 for safety, reliability, and standardized installation in critical fluid-handling systems.

Which seal models are best suited for slurry, abrasive, or solids-laden media?

The SPS-610 and SPS-625 double cartridge seals are specifically designed for slurry applications, featuring vortex breakers and wear-resistant components

What is the maximum operating pressure, temperature, and shaft speed your seals can handle?

Depending on the model, seals can operate at up to 40 barg, 350°C, and shaft speeds of 20–25 m/s

Can HydroMax seals be integrated with existing seal support systems?

Yes. Our designs are fully compatible with API piping plans (32, 52, 53, 62), making them straightforward to integrate into existing pumping systems.

What’s the main advantage of choosing a cartridge seal over a component seal?

Cartridge seals are pre-assembled and factory-tested, reducing installation errors and downtime, whereas component seals provide flexibility and cost efficiency for OEM applications.

Do you provide material options for specific chemical or high-temperature services?

Yes. We offer a wide range of seal face combinations (Carbon, SiC, Tungsten Carbide, Antimony Carbon) and elastomers (Viton, Aflas, Kalrez) to match process conditions.

How can HydroMax seals improve equipment uptime and reduce lifecycle costs?

Our cartridge designs minimize human error during installation, extend service intervals, and reduce the need for unplanned maintenance.

Do you offer engineering support for seal selection and system design?

Yes. Our technical team provides application analysis, seal selection assistance, and compatibility checks to ensure the right seal is specified for each project.

What industries benefit most from HydroMax seals?

Key industries include oil & gas, mining, pulp & paper, chemical processing, power generation, and water & wastewater treatment, where uptime and reliability are mission-critical.

Does HydroMax offer refurbishment and aftermarket services for seals in operation?

Yes. We provide refurbishment, testing, and replacement programs to extend the operational life of installed seals and reduce total cost of ownership.
